HE-550 Watts (half cell) 35mm
HE-550 Watts (half cell) 35mm
- Regular price
- $490.00
- Regular price
-
- Sale price
- $490.00
- Unit price
- per
Tax included.
Shipping calculated at checkout.
High-efficiency panels are ideal for homes seeking a visually pleasing solar panel and for roofs where space is tight.
- suitable for outdoor and household solar energy environmental power generation systems.
- This 550W Monocrystalline solar panel design had the highest efficiency which produces the most power compared.
- The product is suitable for off-grid situations, including solar green lights, solar light box billboards, solar insecticidal lamps, house solar power generation system, ship solar power generation system, field survival solar power generation system, etc.
Mechanical Properties
| Cell Configuration |
144 Cells (6 x 24) |
| Cell properties |
Monocrystalline |
| Number of Busbars | 5 BB |
| Dimensions (L x W x H) |
2279 x 1134 x 35mm |
| Wind Load (test) | 2400Pa |
| Snow Load (test) | 5400Pa |
| Weight | 27.7kg |
| Connector Type |
|
| Junction box ingress protection |
|
| Length of Cable |
|
| Glass (Materials) |
|
| Frame |
|
Electrical Properties
| Maximum Power Pmax (W) | 550 |
| MPP Voltage Vmpp (V) | 41.76 |
| MPP Current Impp (A) | 13.17 |
| Open Circuit Voltage Voc (V) | 50.11 |
| Short Circuit Current Isc (A) | 14.49 |
| Module Efficiency (%) |
18 ~ 20 |
| Operating Temperature (°C) | -40 to +85 |
| Maximum System Voltage (V) |
|
| Maximum Series Fuse Rating (A) |
20
|
| Power Tolerance (%) |
-3 ~ +3
|
